Build and Deploy a Free Customer Support AI Agent with Hexabot, OpenRouter, and Railway on a Live Website

What We Are Building

We are building a customer support AI agent: a bot that greets visitors on your website, reads their question, looks up the answer in your own documentation, and replies in plain language. The architecture has four moving parts, and every one of them has a free tier.

The agent's logic inside Hexabot is a three-step workflow:

user message  →  retrieve_rag_content  →  ai_generate_reply (grounded)  →  send_text_message

Prerequisites

• A Hexabot project pushed to a GitHub repo (the official starter works as-is)
• A Railway account
• An OpenRouter API key
• A Next.js website (this guide uses the App Router)

Part 1: Deploy Hexabot on Railway

1. In Railway, create a new project and Add → Database → PostgreSQL.
2. Add → GitHub Repo and select your Hexabot repo. Railway builds the Dockerfile automatically.
3. On the app service, open Settings → Networking → Generate Domain to get a public URL.
4. Open Variables and paste the full list from the reference section below.

The starter ships with a Dockerfile whose production stage runs node dist/main. Railway injects PORT automatically, so never hard-code it.

The five mistakes that crash a fresh deploy

Each of these produced a real crash loop on the first deploy. Set the variables right and you skip all of them.

When the deploy is green, visit your domain and log in with the SEED_ADMIN_EMAIL / SEED_ADMIN_PASSWORD you set, then change the password.

Part 2: Add the OpenRouter Model Credential

In the Hexabot admin, go to Credentials and create one named OPENROUTER_API_KEY with your OpenRouter key as the value. Credentials are stored encrypted and are never exposed back through the API. The workflow references them by id.

Part 3: Build the Base Support Agent Workflow

Create a conversational workflow. A minimal echo-of-the-LLM bot is three definitions and a flow:

defs:
  openrouter:
    kind: model
    settings:
      provider: openai-compatible
      model_id: "nvidia/nemotron-3-ultra-550b-a55b:free"
      base_url: https://openrouter.ai/api/v1
      api_key: <OPENROUTER_API_KEY credential id>   # selected on the model node
  reply:
    kind: task
    action: ai_generate_reply
    inputs:
      input_mode: prompt
      prompt: "=$input.text"
      system: "You are a friendly customer support agent. Answer clearly and concisely."
    bindings:
      model: openrouter
  send:
    kind: task
    action: send_text_message
    inputs:
      text: "=$output.reply.text"
flow:
  - do: reply
  - do: send

Publish it, send a test message in the console, and confirm you get a reply. Now we make it grounded.

Part 4: Upgrade to a RAG Agent

Step 1: Create a CMS content type

Create a content type (e.g. GenAI Articles) with three fields beyond the built-in title: body, url, and the status flag. Hexabot automatically builds a combined searchText field per record (title + url + body). Lexical retrieval searches that field.

Step 2: Ingest your articles

Add one CMS record per article (title, body, url, status: true). This is where a subtle trap lives:

You can verify the knowledge base is live by running a retrieval query in the admin and confirming it returns hits with "source": "lexical".

Step 3: Wire the RAG flow

Add a retrieve_rag_content step before the reply, and inject its output into the prompt so the model answers only from retrieved context:

defs:
  openrouter:
    kind: model
    settings:
      provider: openai-compatible
      model_id: "nvidia/nemotron-3-ultra-550b-a55b:free"
      base_url: https://openrouter.ai/api/v1
      api_key: <OPENROUTER_API_KEY credential id>
  retrieve:
    kind: task
    action: retrieve_rag_content
    inputs:
      query: "=$input.text"
    settings:
      mode: lexical
      limit: 4
      content_type_id: <GenAI Articles content type id>
      include_inactive: false
  reply:
    kind: task
    action: ai_generate_reply
    inputs:
      input_mode: prompt
      prompt: "=('Use ONLY the context below to answer. If it is empty or irrelevant, say you are not certain and point the user to the website.\n\nCONTEXT:\n' & $output.retrieve.text & '\n\nQUESTION: ' & $input.text)"
      system: "You are a customer support agent. Answer clearly and concisely, grounded only in the provided context."
    bindings:
      model: openrouter
  send:
    kind: task
    action: send_text_message
    inputs:
      text: "=$output.reply.text"
flow:
  - do: retrieve
  - do: reply
  - do: send

Publish the workflow. Your customer support agent now answers from your own content.

Part 5: Embed the Widget on Your Next.js Site

Step 1: Create a Web source

In the admin, Integrations → Channels → Add → web. Set a name, add your website origins to Allowed domains (exact origins, with scheme), pick the default workflow, and copy the Source Ref.

https://yourwebsite.com,https://www.yourwebsite.com,http://localhost:3000

Step 2: Add the client component

The widget ships as a UMD bundle built against React 18, while a modern Next.js app runs React 19. Importing it into the bundle risks dual-React hook errors. The safer approach is to load it at runtime on its own isolated React 18, and mount it into its own div.

Create a small client component, src/components/HexabotChat.tsx.

Inside a useEffect, it does four things:

1. Adds tiny window.process and window.require shims so the bundler-oriented UMD runs from a plain <script> tag.
2. Loads React 18, ReactDOM 18, and the widget UMD + CSS from the CDN.
3. Mounts the widget into a div with ReactDOM.render(...) once those scripts are ready.
4. Wraps that div in a max z-index stacking context so the launcher is always clickable.

The only values you change are your API URL and Source Ref, passed as widget props:

ReactDOM.render(
  React.createElement(HexabotWidget, {
    apiUrl: 'https://your-app.up.railway.app/api',
    channel: 'web',
    sourceId: 'YOUR_SOURCE_REF',
    language: 'en',
    transport: 'ws',
  }),
  document.getElementById('hexabot-chat-widget'),
);

Then render the component once in src/app/layout.tsx so it appears on every page:

import HexabotChat from '@/components/HexabotChat';

export default function RootLayout({ children }: { children: React.ReactNode }) {
  return (
    <html lang="en">
      <body>
        {children}
        <HexabotChat />
      </body>
    </html>
  );
}

Troubleshooting Cheat Sheet

Complete Environment Variable Reference

Paste this into your Railway app service (use the Raw Editor). Railway injects PORT automatically, so do not add it.

node -e "console.log(require('crypto').randomBytes(32).toString('hex'))"

# --- Runtime ---
NODE_ENV="development"            # MUST be development, or the admin is never seeded
HTTPS_ENABLED="true"              # Railway terminates TLS in front of the app
API_IS_PRIMARY_NODE="true"

# --- Public networking (use YOUR Railway domain + your site) ---
APP_DOMAIN="your-app.up.railway.app"
API_ORIGIN="https://your-app.up.railway.app/api"
FRONTEND_BASE_URL="https://your-app.up.railway.app"
FRONTEND_ORIGIN="https://your-app.up.railway.app,https://yourwebsite.com,https://www.yourwebsite.com"

# --- Database ---
DB_TYPE="postgres"
DB_URL="${{Postgres.DATABASE_URL}}"   # Railway reference variable
DB_AUTO_MIGRATE="true"
DB_SYNCHRONIZE="true"             # required so a fresh Postgres builds its schema
DB_SCHEMA="public"
SESSION_LIMIT_SUBQUERY="true"

# --- Secrets (GENERATE YOUR OWN, do not reuse these placeholders) ---
SESSION_SECRET="<64-hex-chars>"
JWT_SECRET="<64-hex-chars>"
JWT_EXPIRES_IN="24h"
PASSWORD_RESET_SECRET="<64-hex-chars>"
CONFIRM_ACCOUNT_SECRET="<64-hex-chars>"
SIGNED_URL_SECRET="<64-hex-chars>"

# --- Seed admin (created on first boot) ---
SEED_ADMIN_EMAIL="you@example.com"
SEED_ADMIN_FIRST_NAME="Your"
SEED_ADMIN_LAST_NAME="Name"
SEED_ADMIN_PASSWORD="<a-strong-password>"

# --- MCP + uploads ---
MCP_ENABLED="true"
UPLOAD_DIR="/uploads"             # NOT /app/uploads (it doubles to /app/app/uploads)
STORAGE_MODE="disk"

Wrapping Up

You now have a free, self-hosted customer support AI agent: deployed on Railway with Postgres, powered by a free OpenRouter model, answering from your own CMS content, and live in a chat bubble on your website. The tricky parts were never the happy path. They were the silent defaults (SQLite, production seeding, the doubled uploads path) and the RAG index getting skipped on parallel inserts. With the variable reference and cheat sheet above, you can rebuild the whole stack without hitting any of them.

All secrets shown in this guide are placeholders. Always generate fresh, unique secrets for your own deployment.
